World best a comprehensive supplier with full-line brand vehicles.
| Product combination element | Brand | VIEW CS2 | ||
| Vehicle Model | BJ6549B1PDA-RA | |||
| Fuction | Passenger | |||
| Product ID | 6549B1PDA-RAZA47 | |||
| Drive type | RHD | |||
| Body | Wide-body & High roof | |||
| Back door | Lifted back door | |||
| Sliding door | Single sliding door | |||
| Engine | Model | F2.8s4129P | ||
| Emission | EuroIV | |||
| Fuel type | Diesel | |||
| Power（Kw/rpm） | 96/3600 | |||
| Torque（N·m/rpm） | 280/1400~3000 | |||
| Displacement（ml） | 2780 | |||
| Transmission | 5MT | |||
| Main technical parameter | ||||
| Dimension parameter | ||||
| Outer dimension（mm） | 5300×1920×2285 | |||
| Wheel base（mm） | 3110 | |||
| Mass parameter | ||||
| Gross Vehicle Weight(GVW) (kg) | 3400 | |||
| Kerb Weight(kg) | 2140 | |||
| Loading weight (kg) (including persons) | ||||
| Capacity (Person) | 2 | |||
| Seats Layout | ||||
| Power performance | ||||
| Max.speed（km/h） | ≤145 | |||
| Fuel economy | ||||
| Integrated operating condition of 100 km fuel consumption (full load)(L/100km) | ≥9.5 | |||
| Function configuration | ||||
| Chasis system | ||||
| Wheel assy | Tyre | 195R15C | ||
| Steel ring+Cover | × | |||
| Aluminium alloy | ● | |||
| Brake safety device | Load sensing proportioning valve | × | ||
| ABS+EBD | ● | |||
| Interior trim | ||||
| Type | Ordinary gray | ● | ||
| Half a pack / all-inclusive | Half pack of interior | × | ||
| Full package interior | ● | |||
| Ceiling | PVC+Non-woven | × | ||
| Polyurethane + non-woven | ● | |||
| PVC | × | |||
| Steering wheel | Adjustable angle of the steering wheel | ● | ||
| Ordinary PU | × | |||
| Genuine leather | ● | |||
| Carpet assembly | Chemical fiber | × | ||
| PVC | ● | |||
| Wooden floors | × | |||
| Aluminum alloy | × | |||
| Seat | Airline seats | × | ||
| Seat fabric | Knitting | × | ||
| Woven cashmere | ● | |||
| Simulation Paper | × | |||
| Three-point type driver and Co-driver | ● | |||
| The number of sun visors | 2 | |||
| Body and accessories | ||||
| Skylight | × | |||
| Top of the escape hole | × | |||
| Number of side sliding door | 1 | |||
| Front and rear bumpers | Body colored bumpers（Without striae） | ● | ||
| Black bumper（With striae） | × | |||
| Blind window | Total blindness | × | ||
| Half-blindness | × | |||
| Back door | Glass | |||
| Body Glass | Tawny | × | ||
| Transparent glass | ● | |||
| window of body | Side sliding door | Sliding window / level the window | × | |
| Body | Number of Sliding window | 3，Left rear/right front/right rear | ||
| Number of level window | × | |||
| Door lock | Mechanical lock | × | ||
| Central locking (Integrated key) | ● | |||
| Front door | Manual windows | × | ||
| Power window | ● | |||
| Outside rear-view mirror | Manual | × | ||
| Electric(Manual folding) | ● | |||
| Outside rear-view mirror housing | Same to body colour | ● | ||
| Black housing | × | |||
| Chrome casing | × | |||
| Rear attachment | Rear wiper+Rear washer | ● | ||
| Rear defroster | ● | |||
| Rear Mirror | ● | |||
| Safety | ||||
| Airbags | Driver's air-bag assy | ● | ||
| Assistant driver airbag | ● | |||
| lamps and lanterns | Front fog lamp | ● | ||
| Daytime running lights ( DRL ) | × | |||
| high-mounting brake lamp | ● | |||
| Reverse radar(singing) | ● | |||
| Body sound and light alarms | ● | |||
| Comfort | ||||
| Air-conditioner system | Air conditioner | Front | ● | |
| Rear | ● | |||
| Warm braw | Front | ● | ||
| Rear | ● | |||
| Each row independent outlet | ● | |||
| Ionizers | × | |||
| Audio device | Radio +AUX+USB | ● | ||
| CD | × | |||
| Reverse image+DVD | × | |||
| Blue-tooth | × | |||
| Number of speakers | 2 | × | ||
| 4 | ● | |||
| Others | ||||
| Others | Side outside antenna | ● | ||
| Central storage box | ● | |||
| Driver's rear guardrail | × | |||
| Front and rear cabin bulkhead | ● | |||
| Remarks | ||||
| Minibus Unit Price FOB Qingdao （USD） | ||||
| Basic Ambulance Medical Equipment List | ||||
| Number | Quantity | Type | Equipment Name | |
| 1 | 1 | Alarm System | LED Warning Light Alarm(Strobe) | |
| 1 | Snail Lamp | |||
| 2 | 1 | Partition | FRP Partition with Sliding Window | 玻璃钢推拉窗隔断 |
| 3 | 1 | Seat | Foldable Monitoring Seat (Including Seat Safety Belt) | |
| 1 | Three-seat (with Toolbox and Safety Belt) without Armrests | 座椅 | ||
| 1 | Forward Single Seat | |||
| 4 | 1 | Medicine Cabinet | L-type Combination Medicine Cabinet | |
| 5 | 1 | Stretcher | Automatic Loading Stretcher | 自动装载担架 |
| 1 | Stretcher backsplash | 担架后挡板 | ||
| 1 | Stair stretcher | 楼梯担架 | ||
| 6 | 2 | Oxygen System | 10L Oxygen Cylinder | |
| 1 | Oxygen supply system | |||
| 1 | Oxygen cabinet | |||
| 7 | 1 | Infusion System | Sliding Bottle Holder | 输液系统 |
| 8 | 1 | Lighting System | LED Indoor Lighting | 照明系统 |
| 9 | 1 | Floor | PVC Floor | |
| 10 | 1 | Power System | 1000W inverter + power distribution system (12V/220V socket) | |
| 11 | 1 | Dirt Bucket | Stainless Steel Dirt Bucket | 污物桶 |
| 12 | 1 | Disinfection System | UV Disinfection Lamp | 消毒系统 |
| 13 | 1 | Ventilation System | Ventilation Fan | 通风系统 |
| 14 | 1 | Window Film | Frosted Film | 玻璃贴膜 磨砂膜 |
| 15 | 1 | Fire Extinguisher | 2Kg Fire Extinguisher and Bracket | 灭火器 |
| 16 | 1 | Appearance Logo | Red Cross Logo, Reflective Color Strip, AMBULANCE Logo | |
